Home > Products > Clay brick making machine > 8000-24000pcs per hour JKY SERIES CLAY BRICK MAKING MACHINE /VACUUM EXTRUDER
8000-24000pcs per hour JKY SERIES CLAY BRICK MAKING MACHINE /VACUUM EXTRUDER
- 20 Set / Sets per Month
- Qingdao
- T/T L/C PayPal Other
- 30 days
- Hand press block making machine QTJ4-50
- Pioneer high capacity AAC Block Production Line
- China pe200x300 smallest jaw crusher
- XIEXING XQY2000 Hydraulic pressure molding machine for sale
- High Capacity Clay Brick Making Machines With 20stripe/M 18.8kw Power CE / ISO Certificate
- High Speed Clay Brick Cutting Making Machine 12000kg With 36000pcs/Hr Capacity
Product Details
Brand Name: | LINGHENG | Place of Origin: | China | Model Number: | JKY50-4 |
Certification: | ISO | Type: | Other, clay brick making machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Warranty: | 1year | Dimension(L*W*H): | 5300*4500*3000MM | Voltage: | 380V |
Power: | (180+55+15)KW | Condition: | New | Automatic: | Yes |
Capacity: | 11000-15000pcs/h | Method: | Vacuum Extruder | Processing: | Brick Molding Machine |
Brick Raw Material: | Clay |
Product Description
1. Reasonable design,Compact structure,Simple opetation
2. Simple opetation and easy maintenance
3. Lower energy consumptionand high quality
4. ISO9001:2008 approved
TECHNICAL DATE OF JKY CLAY BRICK MAKING MACHINE /VACUUM EXTRUDER
Type | Capacity (pcs/hr ) | Reamer diameter (mm) | Extruding pressure (mpa) | Forming liquid water content % | Max vacuum degee (mpa) | Power (kw) |
JKY 75/75-4.0 | 20000-24000 | 750 | ≤4.0 | 14-16 | ≤-0.092 | 90/285/22 |
JKY 70/70-4.0 | 18000-22000 | 700 | ≤4.0 | 14-16 | ≤-0.092 | 90/250/22 |
JKY 60/60-4.0 | 16000-20000 | 600 | ≤4.0 | 14-16 | ≤-0.092 | 75/200/22 |
JKY 55/55-4.0 | 14000-18000 | 550 | ≤4.0 | 14-16 | ≤-0.092 | 75/160/15 |
JKY 50/50-4.0 | 11000-15000 | 500 | ≤4.0 | 14-16 | ≤-0.092 | 55/132/15 |
JKY 45/45-4.0 | 8000-12000 | 450 | ≤4.0 | 14-16 | ≤-0.092 | 55/110/15 |
JKB 60/60-3.0 | 18000-22000 | 600 | ≤3.0 | 16-18 | ≤-0.092 | 75/185/15 |
JKB 55/55-3.0 | 15000-19000 | 550 | ≤3.0 | 16-18 | ≤-0.092 | 75/160/15 |
JKB 50/50-3.0 | 12000-16000 | 500 | ≤3.0 | 16-18 | ≤-0.092 | 55/132/15 |
JKB 45/45-3.0 | 10000-14000 | 450 | ≤3.0 | 16-18 | ≤-0.092 | 45/110/15 |
JKB 40/40-3.0 | 8000-12000 | 400 | ≤3.0 | 16-18 | ≤-0.092 | 45/90/15 |
JKB(SJ) 50/50-4.0 | 12000-18000 | 500 | ≤4.0 | 14-22 | ≤-0.092 | 160/15 |
JKB(SJ )45/45-3.0 | 10000-16000 | 450 | ≤3.0 | 16-22 | ≤-0.092 | 132/15 |
JKB(SJ) 40/40-2.0 | 10000-14000 | 400 | ≤2.0 | 18-22 | ≤-0.092 | 110/15 |
JKB(SJ) 35/35-1.5 | 8000-12000 | 380/350 | ≤1.5 | 18-22 | ≤-0.092 | 75/15 |
Contacts:
WhatsApp: +8613223066055; Email: sales@sinolingheng.com
