F-DZW 10-250 Series Intelligent Electric Actuator

Multi-Rotation F-DZW 10~30 Intelligent Integrated Switching Electric Actuator

Summary

This series of electrical fittings have the characteristics of full function, reliable performance, advanced control system, small size, light weight, convenient use and maintenance, etc. The valve can be controlled remotely, centrally and automatically. It is widely used in electric power, metallurgy, petroleum, chemical industry, paper making, sewage treatment and other industries.

The performance of this product meets the requirements of JB/T8528-1997

According to the protection type, the multi-rotating electric device can be divided into outdoor type and flameproof type; according to the control mode, it can be divided into standard type, switch type and regulation type; and according to the connection type, it can be divided into torque type, power station type and thrust type.

Working environment and main technical parameters

2. Working environment and main technical parameters "C2.1 power supply: conventional, three-phase 380V (50Hz)

Special, three-phase 660V, 440V, 415V (50Hz, 60Hz);

Single-phase 220V, 110V (50Hz, 60Hz) 2.2 working environment:

2.2.1 ambient temperature: - 20 ~ + 60C (special order - - 40 ~ + 80 * C). 2.2.2 Relative humidity:<95% (25C).

2.2.3 Protection Type: Outdoor type for places without flammable, explosive and corrosive media. Flameproof products are D | and dII BT4. D | is suitable for non-mining face in coal mine; dIIBT4 is used for workers.

The plant is suitable for explosive gas mixtures with IA and II B class T1-T4. (See Pu GB3836.1 for details)

2.2.4 Protection Level: IP65 (Special Order IP67, IP68). 2.3 Working System: Short 10 minutes (30 minutes for special orders).
